Page #56 background imageLoading...
Page #56 background image
56 17-08-2004 123312 03
THERMAL SPECIFICATIONS ITC-320 A
Influence from load :
0.2°C / 0.36°F @320°C / 608°F
Influence from load with
ext. reference :
0.03°C / 0.05°F @320°C / 608°F
Difference between inserts:
0.10°C / 0.18°F
Long term drift (1 year) :
±0.10°C / ±0.18°F
Calibration accuracy (test limit) ±0.15°C / ±0.27°F
Temperature coefficient 0.03°C/°C (0-40°C) / 0.05°F/°F (32-104°F)
Stability ±0.03°C / ±0.05°F
Reference accuracy ±0.10°C / ±0.18°F
Total accuracy ±0.30°C / ±0..54°F
Heating time incl. insert 50°C / 122°F to 320°C / 608°F : 7 min.
Additional stabilisation time 10 min.
Cooling time incl. insert 320°C / 608°F to 100°C / 212°F: 30 min.
320°C / 608°F to 50°C / 122°F : 60 min.
THERMAL SPECIFICATIONS ITC-650 A
Maximum temperature 650°C / 1202°F
Minimum temperature 10°C / 50°F @ ambient temperature 0°C / 32°F
33°C / 91°F @ ambient temperature 23°C / 73.4°F
50°C / 122°F@ ambient temperature 40°C /
104°F
