21
Connecting 11
#
& 12
#
(NC) of limit switch to
terminals 3
#
& 5
#
of
control box
1.Wire connecting for high limit switch
2、Wire connecting for low limit switch wire
1#
2#
90º
Connect limit switch 11
#
& 12
#
terminal to
control box 1
#
& 2
#
terminal
3#
5#
90º
