Oil
Outlet
Oil
return
port
Solenoid
valve
Relief
valve
Throttle
valve
Start
capacitor
Running
capacitor
Check
valve
Oil
outlet
Oil
return
port
Solenoid
valve
Relief
valve
Throttle
valve
Check
valve
b. PEAK electric power unit, 220V/50HZ, 1 phase (See Fig. 52)
C. PEAK electric power unit, 380V/50HZ, 3 phase (See Fig. 53)
Fig.52
Fig.53
