TAF-500 06.2018 / 910101-000115 Page 4 of 16
TECHNICAL SPECIFICATIONS
General
Maximum flow rate
25 m
3
/hr; 110USgpm
Consult manufacturer for optimum flow depending on
filtration degree & water quality.
Min. working pressure
1.5 bar; 22psi
Or lower if pressure is increased for flushing.
Max. working pressure
8 bar; 120 psi
Filter area
465 cm
2
; 72 in
2
Inlet/Outlet diameter
50 mm; 2"
Threads: BSP or NPT
Max. working temperature
60
0
C; 140
0
F
Weight
11.6 kg; 25.6lb
Flushing data
Exhaust valve
40 mm; 11/2"
Flushing cycle time
16 seconds
Wasted water per cycle
18 liter; 4.7 USgallon
Minimum flow for flushing
4 m
3
/h; 18 USgpm
at 1.5 bar; 22 psi
Flushing criteria
Differential pressure of 0.5 bar (7psi), time intervals and manual operation
Control and electricity
Rated operation voltage
220 V - Single phase
110 upon request
Electric motor
15 Watt
50 / 60 Hz, Gear output 48 / 58 R.P.M.
Current consumption
0.18 A
Control voltage
24 VAC
Construction materials
Filter housing and lid
NYLON
Screens
St.St. 316 Weave Wire screen with Polypropylene construction
Cleaning mechanism
PP, Delrin
Exhaust valve
Plastic, Natural rubber
Seals
NBR
Control
Brass, Stainless steel, PE, PP
Standard filtration degrees
Stainless steel screen
micron
500
300
200
130
100
80
50
25
10
mm
0.5
0.3
0.2
0.13
0.1
0.08
0.05
0.02
0.01
mesh
30
50
75
120
155
200
300
450
600
