1, Receiver
2, Power cable
3, Antenna of receiver
4, 4 "a" rechargeable battery of receiver
5, Charger of receiver
6, Transmitter
7, Power cable of transmitter
8, Antenna of transmitter
9, Sonar senser(transducer)
10
transducer
11, Tripod(optional)
-4-
2.2 Method II: Stick the magnet on the bottom of boat by glue (see
illustration), make the the magnet on the transducer magnetize with
the one on the boat.
Note: Tightening the screws.
2 Mounting the transducer
2.1Method I:Remove the cover under the bait boat, put the
transducer into the hole and keep the bottom of transducer to face
outside (see illustration), fixing it by the screws.
Note: Make sure the magnet is kept to be horizontal with
bottom of boat when it is fixed.
Fixing
Magnet
Magnetize
Remove
Fixing
