Plug the power cable connector into the socket on the back of the
display tightly and another side to the battery compartment.
-7-
Plug one side of charger's cable
connector into the DC socket of
receiver, another side into the AC
power, the red indicator light and
charging is started. The indicator
turns green when power is full.
Warning!!!
The chargers are different for transmitter and
receiver. Correct using must be requested according to the
instruction on the charger and this guide, otherwise the
damage will be caused!
4.3 Connecting the Power Cable
4.4 Assembling the tripod(tripod is optional)
5 Charge the battery of receiver
Screw the tripod in the screw thread socket on the bottom of
battery compartment tightly(see illustration)
Screw tightly
Plug into
