135.9
5.35
151.6
5.97
69.1
2.72
9.9
.39
9.9
.39
393.3
15.48
MCBH8M
WEIGHT CONNECTION
POINTS
SS CAGE
INSTRUMENT CONNECTION
POINT
SHORTING PLUG LANYARD
CONNECTION POINT
INSTRUMENT DEPTH
RATING
(100 OR 500 m)
ACETEL HOUSING
5.5
.22
INSTRUMENT STATUS
INDICATOR
Green: battery fully charged
Red: battery low
Orange: instrument charging
Flashing: instrument logging
WiFi / GPS STATUS
INDICATOR
Single blink: WiFi on, GPS lock
Double blink: WiFi on, no GPS Lock
Off: WiFi off, GPS off
CT•XCHANGE
P•XCHANGE
SECONDARY MOUNT
PRIMARY MOUNT
SV•XCHANGE
P•XCHANGE
CTD CONFIGURATION
(CAGE REMOVED)
SVD CONFIGRATION
(CAGE REMOVED)
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF AML OCEANOGRAPHIC LTD.
ANY REPRODUCTION IN PART OR WHOLE WITHOUT THE WRITTEN PERMISSION OF AML OCEANOGRAPHIC LTD IS PROHIBITED
PDC-BSX2-P1S1-05/01
2071 Malaview Avenue W., Sidney B.C. Canada V8L 5X6 (250) 656 0771 Fax: (250) 655 3655
MATERIAL:
TOLERANCES:
UNLESS OTHERWISE SPECIFIED:
ANGLES:
FRACTIONS:
HOLE SIZES:
0.00:
0.000:
1
1/32
0.005(0.13)
0.015(0.38)
0.005(0.13)
ORIGINAL SCALE:1:4
DIM'S ARE IN INCHES (MM)
SURFACE FINISH: 63
DRAWN
DATE
JAN 12/16
C.B.
Sheet1 of 3
SIZE B
BASE•X V2 CUSTOMER OVERVIEW, 500/100 m
DRAWING NO.:
SWP-GA-04108
SLD FILE NO.:
SWP-MA-040704-A
REV
N/A
TITLE:
AML NO.
SHEET NO.
DATE
BY
DESCRIPTION
REV
REVISION TABLE
3rd ANGLE
PROJECTION
REVIEWED
D.O.
