3.4 Ad ju sting / Lo cking the draw bar
3.4.1
Ad ju sting the draw bar
•
By tur ning ad just ment-screw (2), the draw bar (1) can be set to
any po si tions so as ob tain the best wor king height on the
draw bar grip.
3.4.2 Lo cking the draw bar
•
In case of loa ding and trans port the draw bar (1) has to be lo -
cked in an up right po si ti on by tur ning up the lo cking bolt (3.
LM75020000-2 HbmG gnu thci dreV nna mmA © 9102/01
3. Ope ra ti on
53
Be wa re of ma te ri al da ma ge.
If the shaft is locked dur ing nor mal op er a tion, parts of
the lock ing mech a nism can be dam aged.
w
Ne ver lock the shaft du ring nor mal ope ra ti on.
