3.6 En gine op er a tion – Hatz
3.6.1 Start ing the En gine – Man ual start
•
Set the en gine speed le ver (1) to full load (MAX).
•
Slowly pull out han dle (2) with rope, un til de tect able re sis tance
can be felt (I.).
•
Al low the rope to run back in, to en able you to uti lise the whole
length of rope for the start ing pro ce dure (II.).
•
Take hold of the han dle (2) with both hands.
•
Pull the start ing rope with in creas ing speed, un til the mo tor
starts up.
B3299089
1
MAX
B1799202.cdr
S
CS
2
I.
II.
B1799203.cdr
SCS
2
B1799204.cdr
2
Important
If the mo tor does not ig nite af ter sev eral un suc cess ful
attemps at start ing, move the speed con trol le ver back
into stop po si tion and pull the start ing rope through
slowly, 5 times. Then re peat the start ing pro ce dure.
3. Ope ra ti on
45
