4.2 Trans port trolley
1)
The trans port trol ley can be used for prob lem-free trans port of
the ma chine.
•
Po si tion the tow ing bar (1) vertically.
•
Re move the un der car riage (2) from the mount ing bracket (3)
and place it on the floor.
•
Po si tion the tow ing bar (1) hor i zon tally and lock in po si tion (4).
•
With the tow ing bar locked in po si tion tip the ma chine on to the
front edge, the un der car riage will swing un der the board.
Danger
Dur ing lon ger work breaks, e.g. at the end of the
work day, do not place the ma chine on the trans -
port trol ley so that the sta bil ity of the ma chine is
not com pro mised.
Take care when rid ing over un even or slop ing
floors. The ma chine can slip or tip over.
Be care ful when rais ing and low er ing the ma chine.
Do not place your feet un der the raised base plate.
Dan ger of foot in ju ries!
4. Trans port
51
