FIRERAY PRODUCT GUIDE
Page 24
8.3 FIRERAY Reflected Range
8.3.1 FIRERAY 50R 100R
The FIRERAY 50R / 100R is a modern design resulting primarily from the desire to reduce the
installation costs: the wiring is only required to the single transceiver unit whilst the Reflector is only
mechanically installed.
The FIRERAY 50R covers an area up to 50 metres in length, using one Reflector.
The FIRERAY 100R covers an area beyond 50 metres and up to 100 metres, using 4 Reflectors
8.3.2 Accessories
The following accessories can be supplied with FIRERAY 2000
LLT Remote Test Station
Allows testing of the Optical Beam Smoke Detector from ground level. The device is compatible with
both the FIRERAY 50R and 100R
Data Link Cable
A pre-wired 2 conductor cable used to send data from the Optical Beam Smoke Detectors to the LLT
station
Reflector (Prism)
Replacement unit for both the FIRERAY 50R and 100R
