Ampeg BA-108 Owner’s User Manual

BA-108 / BA-110 Bass Guitar Combo
7
BA-108 / BA-110 Block Diagram:
EFFECTS LOOP
POWER
AMPLIFIER
VOLUME
SEND RETURN
BASS
MID
TREBLE
TONE CONTROL CIRCUITRY
CD INPUTS
HEADPHONES
OUTPUT
LINE OUT
INPUTS
-15 dB
0 dB
CD LEVEL
25 W [BA-108]
35 W [BA-110]
8" speaker [BA-108]
10" speaker [BA-110]

Ampeg BA-108 Owner’s Specifications

General

Power Output	20 watts
Speaker Size	8 inch
Tone Controls	Bass, Treble
Inputs	1 x 1/4" (instrument)
Speaker	1 x 8"
Controls	Volume, Bass, Treble
Outputs	1 x 1/8" headphone output
