Ampeg SVT-CL Owner's Guide

Ampeg reserves the right to change specifications without notice.
Ampeg is proudly Made in America. ©1999 SLM Electronics, 1400 Ferguson Avenue, St. Louis, MO 63133 U.S.A.
P/N 47-509-23 • 06/99
SVT CLASSIC
www.ampeg.com
Technical Specifications
OUTPUT POWER RATING 300 watts RMS minimum continuous @ <3% THD into 2 or 4Ω, 0.4VRMS input
TOTAL SYSTEM GAIN 67dB @ 1kHz with levels up and tones flat, -3dB @ 40Hz and 15kHz
TONE CONTROL RANGE
BASS: ±12dB @ 40Hz
MIDRANGE: +10dB, -20dB @ 220, 450, 800, 1.6k or 3kHz
TREBLE: +15dB, -20dB @ 4kHz
ULTRA LOW: +2dB @ 40Hz, -10dB @ 500Hz
ULTRA HIGH: +9dB @ 8kHz
SIGNAL TO NOISE RATIO 80dB typical
TUBE COMPLEMENT 12AX7 (3), 12AU7 (2), 6550 (6)
POWER REQUIREMENTS 115VAC, 60Hz, 460VA; 100/115VAC, 50/60Hz, 460VA; 230VAC, 50/60Hz, 460VA
SIZE (W x H x D) AND WEIGHT 24” W x 11.5” H x 13” D, 80 lbs.
In the event that your
SVT CLASSIC should stop
working properly, or just
stop working, take a few
minutes to troubleshoot it
before you call for service.
You can save yourself a lot
of time and sometimes
money doing it yourself,
and often the problem is
something quite simple.
Please refer to the
Troubleshoointg Diagram
for guidelines. If you think
the problem may be worn
out tubes, see page 7 for
symptoms of tube failure.
DISCONNECT all external devices
except bass and speaker cabinet.
No sound, bad sound?
LED's on?
Power LED green?
Green Bias LEDs on?
Instrument volume up?
Sound OK?
Go for it!
Check AC outlet, power cord,
power switch, fuses. Retry
Check Standby switch (20 second
delay when first turned on). Retry
Rebias or see Page 7 for
possible faults. Retry.
Set controls. Retry.
Bias LED's flashing red
with signal?
Possible power amp
problem.
Check speaker cables.
Retry.
If these steps fail to solve
problem, see below.
If the problem isn’t covered above, or if the steps lead you here, then contact your Ampeg
dealer for service information. Also, you should refer your amp to an authorized service center
for servicing if it gets dropped, has liquid spilled into it, or sustains damage to its power cord.
Troubleshooting
Troubleshooting Diagram:

Ampeg SVT-CL Specifications

Power

output power rating	300 watts RMS
power requirements	115VAC, 60Hz, 460VA; 100/115VAC, 50/60Hz, 460VA; 230VAC, 50/60Hz, 460VA

Tone Control Range

bass	±12dB @ 40Hz
midrange	+10dB, -20dB @ 220, 450, 800, 1.6k or 3kHz
treble	+15dB, -20dB @ 4kHz
ultra low	+2dB @ 40Hz, -10dB @ 500Hz
ultra high	+9dB @ 8kHz

System Specifications

total system gain	67dB @ 1kHz
signal to noise ratio	80dB typical
tube complement	12AX7 (3), 12AU7 (2), 6550 (6)

Weight and Dimensions

size (W x H x D)	24” W x 11.5” H x 13” D
weight	80 lbs
