Ampex 601 - Page 26

www.SteamPoweredRadio.Com
Reference
Symbol
7
8
12
9
53
51
52
54
63
62
61
65
68
66
71
6-2
Description
Rewind Idler Assembly
Idler Wheel with Oilite bearing
Guide Assembly
Cambric Washer .. 24 ID x 7 / 16 OD x . 010 thk
Plastic Retaining Ring
Actuator Spring, 11/64 dia x 1" long
Spring Washer, Clevis Pin, 3/8 x 13 / 16
Switch Deck Assembly
Guard, Switch Top
Lamicoid Washer, Side Lever, 1 /8 ID x 5/8 ODxl/32 thk
Lockwasher, #4 Int. tooth
Screw, #4-40 x 1/2"
Nut, #4-40 Hex
Cotter Pin, 1/16" x 1/2
11
long
Clevis Pin, 1/8 x 15-32" long
Clevis Pin, 1/8 x 21/32
11
long
Clevis Pin, 1 /8 x 27 /32" long
Plain Washer, #10
Hairpin Retainer for 3/16" shaft
Resistor Barri er
Switch Guard, side
Capstan Idler Arm Assembly
Anchor
Arm Sub-Assembly
Roller
Spring, 21/64 x 1-27 /64" long
Clevis Pin, 1 /8 x 15/32
11
long
Motor Assembly
Felt Washer, 15 /64 ID x 3/4 OD x 1/16" thk
Motor
Mounting Plate
Pulley, 60 cps, 7-1/2 ips
50 cps, 7-1/2 ips
60 cps, 3-3/4 ips
50 cps, 3-3/4 ips
Screw, 8-32 x 3/8" long
Sem Fastener, 8 -3 2 x 3/8" long
Soldering Lug
Thrust Disc, Nylon, . 312 dia x 1/16" thk
Drive Belt, Nylon, 60 cps, 7-1/2 ips
50 cps, 7-1/2 ips
60 cps, 3-3/4 ips
50 cps, 3-3/4 ips
Spring, Motor Thrust, 5/16 x 1-7 /8" long
Plunger, Motor Thrust
Spacer, Motor Mounting, 1/4 OD x . 531 long
Ampex
Catalog
Number
6284-1
6285
6288
9482-1
430-005
9368
6314
9064-1-C
9728
6318
LW-2I-4C
MS-12-4-8C
NU-l-4C
401-005
400-007
400-010
400-011
PW-1-l0C
431-002
9726
9727
6235-1
6224
6236-1
6237
6910
400-007
6219
6239
6240
6241-0
6241-1
6241-2
6241-3
MS-12-8-6C
SF-2X-8-6C
SL-1
6934
2871-3
2871-6
2871-7
2871-14
7531
7532
7582
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
Reference
Symbol
60
20
26
24
29
17
19
18
15
16
28
27
23
25
21
22
36
38
32
30
31
35
33
37
Description
Rubber Shockmount
Ball, 1/4
11
dia.
Motor Mount Washer, C.R. S. 13/64 ID x 5/8 OD
Motor Mount Screw, Binder Hd., 10-24 x 7 /8" long
Socket Hd. Set Screw, 8-32 x 1/8 long, cup point
Takeup Arm Assembly
Spring, Conical, l" dia. x 31/32" long
Control Spring, 17 / 32 x 13/16" long
Thrust Washer, . 015 spring steel, 1/4 ID x 3/8 OD
Pivot Arm
Hub, with Shaft
Spring, Clutch "U"
Clutch, Play Takeup
Disc Assembly, with small felt
Disc Assembly, with large felt
Clutch Assembly, fast forward, with Oilite bearing
Link, Turntable Control
Washer, Spring Retaining, Cup
Collar, Drum
Brak e Assembly, Holdback
Use Replacement Holdback Brake Assembly Kit
(Each ket contains two Brake Assemblies)
Lamicoid Washer, 1/4 ID x 1/32" thk
Oilite B ear ing
Ball Bearing
Cotter Pin, 1/16 x 1/2" long
#4 Lockwasher, int. teeth
Binding Hd. Machine Screw, 4-40 x 5/16" long
Hex Nut, 4-40
Socket Hd. Set Screw, 6-32 x 1/8" long
Spring, Turntable Height 11/32 x 9/32" long
Rewind Arm Assembly
Thrust Washer, . 015 spring steel, 1/4 ID x 3/8 OD
Pivot Arm
Hub, with shaft
Spring, Clutch
11
U
11
Disc Assembly, with large felt
Clutch Assembly, rewind, with Oilite bearing
Collar, "Drum"
Collar, Spacer
Holdback Brake Assembly
Use Replacement Holdback Brake Assembly Kit
(Each kit contains two #6320-1 Brake Assemblies)
Lamicoid Washer, 1/4 ID x 1/32" thk
* Items marked with the asterisk (*) are included in Kit #7802.
Ampex
Catalog
Number
7922
420-006 *
2431 *
MS-12-10-14C *
SS-2-8-2Y
6242-1
6137 *
6218 *
6223-1 *
6243
6244
6246
6247
6248-1
6248-2
6251
6253
6254
6293
7974
186-1
422-004
421-019
*
401-005 *
LW-21-4C *
MS-12-4-5C *
NU-l-4C *
SS-2-6-2Y *
6217
6255-1
6223-1
6243
6244
6246
6248-2
6251
6293
6316
7974
186-1
*
*
