Cargo adapter for Thule trailer
1. Remove the nut from the left side of the rear dropout, located next
to the motor. Do not remove the motor torque washer from the
dropout – keep it attached to the axle.
2. Attach the Ampler motor axle adapter to the frame.Use a 19 mm
wrench and make sure the axle adapter is securely fastened.
3. Finally, insert the two security washers, Thule trailer mount and
fasten them by using a 15 mm wrench to tighten the outside bolt.
