14
Ohms
RANGE Accuracy
400.0
Ω
0.8% + 6d
4.000k
Ω
, 40.00k
Ω
,
400.0k
Ω
0.6% + 4d
4.000M
Ω
1.0% + 4d
40.00M
Ω
2.0% + 4d
Open Circuit Voltage: 0.4VDC typical
Capacitance
RANGE* Accuracy**
500.0nF, 5.000
µ
F,
50.00
µ
F, 500.0
µ
F,
3000
µ
F
3.5%*** + 6d
*Additional 50.00nF range accuracy is not
specified
**Accuracies with film capacitor or better
***Specified with battery voltage above
2.8V (approximately half full battery).
Accuracy decreases gradually to 12% at
low battery warning voltage of
pproximately 2.4V
a
DC
µ
A
RANGE Accuracy Burden
Voltage
400.0
µ
A
1.5% + 4d
2.8mV/
µ
A
2000
µ
A
1.2% + 3d
2.8mV/
µ
A
AC
µ
A
RANGE Accuracy Burden
Voltage
50Hz -- 500Hz
400.0
µ
A
2.0% + 5d
2.8mV/
µ
A
2000
µ
A
1.5% + 5d
2.8mV/
µ
A
Hz Frequency
Function
Sensitivity
(Sine RMS)
Range
400.0mV 150mV 10Hz -- 2kHz
4.000V 3.2V 5Hz -- 40kHz
40.00V 25V 5Hz -- 100kHz
400.0V 100V 5Hz -- 100kHz
600V 400V 5Hz -- 5kHz
400.0
µ
A 500
µ
A
10Hz -- 30kHz
2000
µ
A 500
µ
A
10Hz -- 30kHz
Display counts: 5000
Best resolution: 0.001Hz
Accuracy: 0.5%+4d
Diode Tester
Open Circuit
Voltage
Test Current
(Typical)
< 1.6 VDC 0.25mA
Type-K Temperature
RANGE Accuracy*
-20°C TO 300°C 2% + 3°C
-4°F TO 572°F 2% + 6°F
*Type-K thermocouple range & accuracy
ot included
