25
6. SPECIFICATIONS
Features AT-6010-R AT-6010-T CT-400
Measurement
Category
CAT III 600 V CAT III 600 V CAT IV 600 V,
CAT III 1000 V
Operating
Voltage
0 to 600 V AC/DC 0 to 600 V AC/DC 0 to 1000 V AC
Operating
Frequency
Energized: 6.25 kHz
De-Energized: 32.768 kHz
Energized: 6.25 kHz
De-Energized: 32.768 kHz
Wire tracing: 32.768 kHz
AC current measurement:
45 Hz to 400 Hz
Hazardous
Voltage Detection
N/A > 30 V AC/DC N/A
Signal Indications Numeric bar graph display
and audible beep
LEDs N/A
Response Time Tip Sensor (Energized /
De-energized): 500 ms
Battery voltage monitoring:
5 sec
Line voltage monitoring:
1 sec
Battery voltage monitoring:
5 sec
Instantaneous
Current Output of
Signal (typical)
N/A Energized circuit:
HI mode: 60 mA RMS
De-energized circuit:
HI mode: 130 mA RMS
Loop mode: 160 mA RMS
1 mA/A for AC current
measurement with
multimeter
Signal Voltage
Output (nominal)
N/A De-energized circuit:
HIGH: 33 V RMS, 140 Vp-p
With CT-400:
Loop model:
31 V RMS, 120 Vp-p
De-energized circuit:
2.4 V RMS, 24 Vp-p
Range Detection
(open air)
Tip Sensor (Energized):
Max distance via air:
up to 20 ft (6.1 m)
Pinpointing:
approx. 1.97 in (5 cm)
Tip Sensor (De-energized):
Max distance via air:
up to 14.7 ft (4.5 m)
Pinpointing:
approx. 1.97 in (5 cm)
N/A N/A
