6. SPECIFICATIONS
Accessory specifications
Features TL-6000-INTL
Measurement Category CAT III (test leads)
CAT IV (alligator clips)
CAT II (outlet adapters)
Operating Voltage and Current 1000 V, 16 A max. (red/green leads)
600 V, 16 A max. (black lead)
600 V, 10 A max. (alligator clips)
300 V, 10 A max. (outlet adapters)
Operating Temperature 32 °F to 122 °F (0 °C to 50 °C)
Operating Humidity 95%: 50 °F to <86 °F (10 °C to <30 °C)
75%: 86 °F to <104 °F (30 °C to <40 °C)
45%: 104 °F to <122 °F (40 °C to <50 °C)
Storage Temperature and Humidity -4 °F to 140 °F (-20 °C to 60 °C), <95% RH
Operating Altitude 0 to 6561 ft (2000 m)
Pollution Degree 2
IP Rating IP 20
Drop Test 3.28 ft (1 m)
Dimensions Red/black leads: 3.28 ft (1 m)
Green lead: 22.97 ft (7 m)
Alligator clips: approx. 3.74 x 1.77 x 0.94 in (95 x 45 x 24 mm)
Outlet adapters: 2.83 x 0.71 x 0.71 in (72 x 18 x 18 mm)
Weight Approx. 0.78 lb (0.356 kg)
Certifications
