5
INTRODUCTION
This Electrical Tester is for universal applications for
indoor use only. It represents a valuable support for all
testing in handicraft and industrial applications.
The electrical tester is characterized by the following
features.
• AC voltage detection up to 480V, and DC voltage
upto 600V.
• Bright neon AC/DC voltage display.
• Ergonomically and robust housing.
• Snap-in leads are spaced to t to the standard US/
Canada outlet, for easy, one hand operation.
• Integral probe storage for easy carrying.
OPERATION
• Test the electrical tester on a known source.
• Connect both test leads with UUT.
• The voltage is displayed via Neon lamps.
• The instrument with 120, 240, 277, 480V AC range
and 160, 330, 380, 600V DC range.
SPECIFICATION
Voltage Range 120, 240, 277, 480V AC
160, 330, 380, 600V DC
Response Time <0,3s
Frequency Range DC, 0~65Hz
Interal Load approx. 2.0 W/ 600V
Test Current <3.5 mA
Operation Time (DT) 30s
Recovery Time 240s
Temperature Range 5°C ~ +40°C (41°F ~ 104°F)
