2830A-XX SERIES THREE DIVER
PORTABLE COMMUNICATOR USER MANUAL
14
3.5 WIRELESS TENDER (28B) CONTROLS
3.5.1 BASE STATION ON/OFF/VOLUME – control is located on the bottom right side of
the Base Station. It turns on and off the power to the Wireless Tender Base
Station and adjusts the volume level by rotating the knob in either direction.
3.5.2 BASE STATION CHANNELS 1 & 2 – programming buttons are located on the rear
side of the base-station. Up to 3 remote headsets can be programed per channel.
3.5.3 WIRELESS REMOTE HEADSET ON/OFF & VOLUME – controls are located on
the headset ear muff. The top button powers on and off the headset, and the
up/down arrows control the headset volume.
3.5.4 RECHARGEABLE BATTERY – is located on the opposite ear muff from the
controls and boom mic.
