2830A-XX SERIES THREE DIVER
PORTABLE COMMUNICATOR USER MANUAL
283XA-UM
REV 7.0
44
7 PARTS LISTS
The parts lists include both mechanical and electrical parts. The following information will be useful in
interpreting data which is not self-explanatory.
REVISIONS
The parts lists in this manual are for the current model of diver communicator as of the printing date.
To Order Replacement Parts Contact:
Amron International, Inc.
1380 Aspen Way, Vista, California, 92081 U.S.A.
Telephone: (760) 208-6500 Fax: (760) 599-3857
Email: sales@amronintl.com
Web: www.amronintl.com
When ordering replacement parts, you should give as much information as possible to enable us to
supply the correct part. This information should include the part number, description, reference
designator, value, radio model number, and serial number. Failure to provide sufficient information
may hinder our ability to fill your parts orders promptly and correctly.
7.1 PARTS LIST FOR 2830A-XX SERIES FRONT PANEL ASSEMBLIES
REF
PART NO.
DESCRIPTION
2
PBSWITCH
SWITCH PUSH BUTTON SEALED N.O
3
7580K6
SWITCH TOGGLE SPST
4
P16NP-10K
POTENTIOMETER 10K OHM W/KNOB
5
1498-102
JACK, BANANA RED
6
1498-103
JACK, BANANA BLACK
7
1498-107
JACK, BANANA YELLOW
8
5168
SEAL HALF BOOT TOGGLE GREY
9 105-0602-001 JACK, TIP RED
10 105-0603-001 JACK, TIP BLACK
11 ME161-2003 JACK, PHONO W/NYL WSHRS NKL/BLK
14 14002B 5-WAY BINDING POST (BLACK)
15
14002R
5-WAY BINDING POST (RED)
16
LEDHOLDER-BLK.25
MOUNTING CLIP FOR 5MM LED
17
LT2462-24-D51
LED, BI-COLOR RED/GREEN
18
SA818
SPEAKER 8 OHM 15 WATT
19
492
HANDLE ROUND 1.5X5.5X5/16
23
8-32X3/4KTSB
SCREW KNURLED THUMB BRASS 3/4
25 24XX-MIC MICROPHONE ASSY ELECTRET
29 LEDGREEN LEDGREEN BRITE
30 MS-3112E-14-5S CONNECTOR, BOX MOUNTING
31
MS-3181-14C
CAP, SEALING FOR RECEPTACLE
