Setting Up Your Machine
Power Cord
Plug one end of the cord into the rear side of the machine and the other
end into a standard AC power outlet with a surge protector.
If you turn on the power switch, the machine will display software
version and checksum on the screen. A service call number (A/S NO,)
will also display if your service provider stored an A/S call No. on the
machine memory.
Printer
MIB-9 machine has a RS232 serial interface port which allows operator to
connect an external printer (only those are recommended by
AMROTEC®) to print out counting result. To connect printer to the
machine, follow the steps below:
1. Make sure that both the MIB-9 and the Printer are turned off.
2. Plug the cable of printer into the serial port of MiB-9.
3. Turn on the printer and then MiB-9.
CAUTION
If wrong port is used to connect your
Printer, turn off MiB-9 immediately to
avoid electrical shock. Turn on the
machine only after correct Port is
connected to the Printer.
