Section Appendix
Copyright 2009, AMS, Proprietary Information, All Rights Reserved 9-3
P/N 0010-0667, Rev A
Figure 4 Figure 5
7.3 Once the access door is opened, remove the locking clip on the flow switch assembly’s
input water QD.
See Fig. 6
Figure 6
7.4 Disconnect the cooling hoses coming from the resonator and chassis components which
attach to the Particle Filter Assembly and the Flow Switch Assembly, watch for excess
water from the connectors upon removal.
See Fig. 7
To Next Page
