7-1
Troubleshooting Operator Manual 150830-026
1. Cannot turn table ON.
7TROUBLESHOOTING
This section describes the types of Amsco
®
3085 SP™ Surgical Table
malfunctions most likely to occur, and probable causes and corrective actions.
Use the Operator Troubleshooting Chart to identify general problems. Use the
Hand Control Diagnostics Chart to identify problems as indicated by the hand
control LEDs.
If you are unable to correct the problem with the use of the Operator
Troubleshooting Chart or the Hand Control Diagnostics Chart, or if a problem
occurs not described on the charts, please contact STERIS. A trained service
technician will promptly place your equipment in proper working order.
NOTE: Never permit unqualified persons to service the table.
PROBLEM POSSIBLE CAUSE AND CORRECTIVE ACTION
1. Hand control not connected – Connect per
SECTION 3
.
2. Hand control defective – Replace.
1. Table unplugged (electric-powered table only) – Plug in.
2. No facility power (electric-powered table only) – Turn facility
power on.
3. F1 or F2 fuse blown (electric-powered table only) – Replace
fuse(s) per
SECTION 8
.
4. AC power cord defective (electric-powered table only) –
Replace power cord.
5. Batteries totally discharged (battery-powered table only) –
Recharge batteries per
SECTION 6
.
6. Circuit breaker CB-1 tripped (electric-powered table only) –
Reset per
SECTION 8
.
7. Circuit breaker CB-2 tripped (battery-powered table only) –
Reset per
SECTION 8
.
1. Circuit breaker CB-4 tripped – Reset per
SECTION 8
.
2. Circuit breaker CB-2 tripped – Reset per
SECTION 8
.
3. AC power cord defective – Replace power cord.
2. No power to pump motor; table will not
articulate.
3. Motor batteries will not charge (battery-
powered table only).
Operator Troubleshooting Chart
WARNING – PERSONAL
INJURY AND/OR EQUIPMENT
DAMAGE HAZARD: Safe and
reliable operation of this
equipment requires regularly
scheduled preventive main-
tenance, in addition to the
faithful performance of rou-
tine maintenance. Contact
STERIS to schedule preven-
tive maintenance.
To Next Page
