150830-026 Operator Manual Service Procedures
Description Part Number Recommended Spares
Power Cord Types Available
• USA Plug, USA Cord P93909-354
• USA Plug, IEC Cord P56397-682
• Schuko Plug, IEC Cord P56397-687
• Australian Plug, Orange Cord P56397-686 (see NOTE 2)
• English Plug, IEC Cord P56397-684
Hand Controls
• Standard 3085 SP P141210-318
• HERMES
®
-Ready
1
3085 SP P141210-367
• ACT Enabled™ 3085 SP P146664-103
Fuse Applications
See NOTES 3, 4, and 5
• 120 VAC Application
F1 and F2 P93909-225 (6 Amp, USA) 10
F3 P93909-222 (0.5 Amp, USA) 5
F4 (if used) P89371-091 (1 Amp, USA) 5
• 120 VAC Application
(Export):
F1 and F2 P150823-292 (6 Amp, IEC) 10
F3 P129360-586 (0.5 Amp, IEC) 5
F4 (if used) P150823-248 (1 Amp, IEC) 5
• 100 VAC Application
F1 and F2 P150823-292 (6 Amp, IEC) 10
F3 P129360-586 (0.5 Amp, IEC) 5
F4 (if used) P150830-131 (1.6 Amp, IEC) 5
• 220 VAC Application
F1 and F2 P129360-587 (4 Amp, IEC) 10
F3 P129360-585 (0.25 Amp, IEC) 5
F4 (if used) P129360-586 (0.5 Amp, IEC) 5
• 230/240 VAC Application
F1 and F2 P129360-587 (4 Amp, IEC) 10
F3 P129360-585 (0.25 Amp, IEC) 5
F4 (if used) P129360-586 (0.5 Amp, IEC) 5
Batteries See NOTE 1 See NOTE 1
Table 8-1. Amsco 3085 SP Surgical Table Replacement Parts
NOTES:
1. This table uses lead-acid batteries. Lead-acid batteries normally are subject to self-discharge and battery-life
deterioration in long-term storage. Therefore, STERIS does not recommend batteries be procured and then stored as
spare parts. If batteries are procured and stored, they should be kept covered and in a cool, dry area. Stored batteries
should be recharged every six months to minimize life deterioration. Use a charging current commensurate with the
battery amp-hour size. Charge to a floating charge voltage equivalent to 13.6-13.8 volts.
2. The cords are approximately 6 m (20 ft) long, except for the Australian cord which is only 4 m (13 ft) long.
3. USA fuses are AGC or ABC or MTH, and are also for use in Canada.
4. IEC fuses are IEC glass fuses. IEC fuses for F3 and F4 require IEC fuseholder, STERIS part number P129360-654.
5. Motor battery chargers built after September 2001, may be auto-ranging and have no F4 fuse.
One spare of the type you use. If
your plug is not in this list, order
the Power Cord type nearest to
your applications, cut the plug off
and install your plug in its place.
Always use a grounded plug.
1
HERMES-Ready is a registered
trademark of Computer Motion.
