Programming
8
AXB-DMX512 DMX512 Interface
Direct Control Buffer Send_Commands
The direct control buffer is modified by individual output ramps or by preset recalls. The following table
lists the Direct Control Buffer Send_Commands.
Direct Control Buffer Send_Commands
Command Description
DL
Recalls a snapshot of all DMX output
channel in T tenths of seconds.
Time is required here. This affects all DMX512 channels.
Syntax:
"'DL<preset number>T<time>'"
If a Direct Ramp is in progress the last command sent will win for
each output.
Variables:
preset number =1-72
time = 0-65535 (time is in tenths of seconds, except where noted).
Examples:
SEND_COMMAND DMX,'DL1T0'
Recalls preset 1 instantly (in zero seconds).
SEND_COMMAND DMX,'DL72T15'
Recalls preset 72 in 1.5 seconds.
Use the groups and group ramp (‘GR’) command to store and recall
scenes with specific channels. Any other snapshot recall or direct
ramp in progress is halted and the ramp to the new level starts from
the current level.
DR
Ramps the DMX output to the L level in
T tenths of seconds. Time is required.
Sends all specified DMX outputs to the
same level.
The list can be single outputs and/or ranges of outputs separated by
commas. If a Snapshot Preset is in progress then the last command
sent will win for each output.
Do not put more 64 characters total in this command.
Syntax:
"'DR<List of DMX Outputs>L<level>T<time>'"
Variables:
List of DMS Output = 1,2,3,5-10 is a list of single DMX channels with
ranges of DMX channels.
level = 0-255 or 0%-100%. The value can be given in actual steps
0-255 or given as a percentage 0%-100%.
time = 0-65535. Time is in tenths of seconds.
Example:
SEND_COMMAND DMX,'DR1L100%T10'
Ramps DMX Output channel 1 to 100% (full) in 1 second.
Any other snapshot recall or direct ramp in progress for the specified
channels is halted and the ramp to the new level starts from the
current level.
Example:
SEND_COMMAND DMX,'DR-512L50%T10'
Sends all channels to 50% in 1 second.
SEND_COMMAND DMX,'DR-512L127T25'
Sends all channels to 50% in 2.5 seconds.
SEND_COMMAND DMX,'DR10,20-30,35L0T0'
Sends channels 10,20 through 30, and 35 to 0%.
