AMX AXB-DMX512 User Manual

Programming
20
AXB-DMX512 DMX512 Interface
Axcess Level Send_Commands (Cont.)
Command Description
AT
Sets the ramp rate for one Axcess level
in tenths of a second.
This affects any future level up (‘AU’), level down (‘AD’), or level direct
ramp (‘AR’) commands. The specified time determines how long it
takes to go full range. If the group is proportional then Individual
Output rates will be proportional.
Optionally, the up (‘U’) or down (‘D’) times may be specified. Ramp
rates determine how long the level will take to ramp from 0% to 100%
(and 100% to 0%).
If, for example, there is a ramp time of 10 seconds, and the level is
currently at 50%, it will take only 5 seconds to ramp to either 0% or
100%.
Syntax:
"'AT<Axcess level>R<time>{U or D}'"
Variables:
Axcess level = 1 - 8
time> = 0-65535
{}-Parameters in commands that are optional.
Example:
SEND_COMMAND DMX,'AT1R5'
Sets Axcess level 1 to ramp rate to 0.5 second both up and down.
SEND_COMMAND DMX,'AT1R50'
Sets the up and down ramp times for Axcess level 1 to 5 seconds.
SEND_COMMAND DMX,'AT3R35U'
Sets the up ramp time for Axcess level 3 to 3.5 seconds.
SEND_COMMAND DMX,'AT8R5D'
Sets the down ramp time for Axcess level 8 to 0.5 seconds.
AU
Ramps up one Axcess level at the
ramp rate set by the ‘AT’ command.
Ramps until ‘AS’, ‘AR’, or ‘AD’. Note that it is not possible to ramp an
Axcess level if it has not been connected to a DMX input (using the
’AC’ command).
Syntax:
"'AU<Axcess level>'"
Variable:
Axcess level = 1 - 8
Example:
SEND_COMMAND DMX,'AU1'
Ramps up Axcess level 1.
AX
Disconnects a single Axcess level from
a single DMX input.
Syntax:
"'AX<Axcess level>'"
Variable:
Axcess level = 1 - 8
Example:
SEND_COMMAND DMX,'AX1'
Disconnects Axcess level 1 from any DMX input.
AZ
Globally disconnects all Axcess levels
from any DMX inputs.
Stops all ramps.
Syntax:
"'AZ'"
