Modero X Series® Touch Panels
5
MXD/T-700 7" Modero X Series® Touch Panels
Microphone
The MXT-700 contains a built-in microphone above the touch screen for video and audio conferencing capabilities. This
microphone is concealed by the casing.
Audio/Video Capabilities
The MXT-700 has the capability of displaying multiple JPEG and PNG files at one time. The device also supports
streaming motion JPEG video (of the sort used by many IP and Web cameras), as well as MP3 and WAV audio files.
MXT-700-NC
The MXT-700-NC (FG5968-27) No Comm touch panel does not have microphone capability. It otherwise has all of the
functionality of the MXT-700 panel.
MXD-700
The MXD-700 7” Modero X Series Wall/Flush Mount Touch Panels (Portrait Wall Mount: FG5968-08; Landscape Wall
Mount: FG5968-14) are ideal for boardrooms, conference rooms, or auditoriums where a panoramic control surface is
needed to provide access to multiple functions simultaneously while remaining elegantly unobtrusive. In residences, they
are perfect for kitchens, home theaters, or home offices where the panoramic control surface can be used to manage
systems throughout the house.
The MXD-700 features a 7.3" x 4.8" (186 mm x 122 mm), 8.8" (222 mm) diagonal (Landscape) or 4.8" x 7.3" (122 mm
x 186 mm), 8.8" (222 mm) diagonal (Portrait) display, with a viewable area of 6.05" x 3.54" (154 mm x 90 mm), 7.0"
(178 mm) diagonal (Landscape) or 3.54" x 6.05" (90 mm x 154 mm), 7.0" (178 mm) diagonal.
The device communicates via Ethernet (10/100 port, RJ-45 connector, supported IP and IP-based protocols: UCP, TCP,
ICMP, ICSP, IGMP, DHCP, Telnet, FTP, DNS, RFB for VNC, and HTTP) and USB (1 USB host 2.0, Type A port).
The MXD-700 also supports Near Field Communication (NFC) technology (please see the NFC on page 11 for more
information) and Bluetooth keyboard and mouse use via the optional MXA-BT Bluetooth Adapter.
FIG. 4 MXD-700, Landscape Wall Mount
