AMX MST-701 - 10.1 Modero S Series Panel Specifications; MST-1001 (Tabletop) Specs

MST/D-1001 - 10.1" S Series Touch Panels
7
Modero S Series G4 Touch Panels Instruction Manual
MST/D-1001 - 10.1" S Series Touch Panels
MST-1001 (Tabletop)
MST-1001 Specifications
FIG. 6 MST-1001
MST-1001 Specifications
DIMENSIONS (HWD) 6 13/16" x 10 1/16" x 2" (174mm x 255mm x 51mm)
WEIGHT 2.6 lbs (1.179 Kg)
POWER CONSUMPTION • Full-On: 14 W (max)
• Typical: 7.5 W
• Standby: 4.5 W
• Shutdown: 0.7 W
• Start-Up Inrush Current: Not applicable due to PoE standard
EXTERNAL POWER
SUPPLY REQUIRED
Optimal performance requires use of one of the following AMX PoE power supplies (not
included):
• PS-POE-AF-TC, PoE Injector, 802.3AF Compliant (FG423-83)
• NXA-ENET8-2POE, Gigabit PoE Ethernet Switch (FG2178-63)
CERTIFICATIONS • FCC Part 15 Class B
• CE EN 55022
• CE EN 55024
• CE EN 60950-1
• IEC 60950-1
• C-Tick CISPR 22 Class B
• IC CISPR 22 Class B
• UL 60950-1
• VCCI CISPR 22 Class B
•RoHS
•WEEE
Sleep Button
Microphone
USB Port
