MST/D-431 - 4.3" S Series Touch Panels
19
Modero S Series G4 Touch Panels Instruction Manual
MST/D-431 - 4.3" S Series Touch Panels
MST-431 (Tabletop)
MST-431 Specifications
FIG. 10 MST-431
MST-431 Specifications
DIMENSIONS (HWD) 3 1/4" x 5 1/16" x 3 1/8" (82 mm x 128 mm x 79 mm)
WEIGHT 0.9 lbs (.4 Kg)
POWER CONSUMPTION • Full-On: 4 W
• Typical: 3 W
• Standby: 2 W
• Shutdown: 0.7 W
• Start-Up Inrush Current: Not applicable due to PoE standard
EXTERNAL POWER
SUPPLY REQUIRED
Optimal performance requires use of one of the following AMX PoE power supplies (not
included):
• PS-POE-AF-TC, PoE Injector, 802.3AF Compliant (FG423-83)
• NXA-ENET8-2POE, Gigabit PoE Ethernet Switch (FG2178-63)
CERTIFICATIONS • FCC Part 15 Class B
• CE EN 55022
• CE EN 55024
• CE EN 60950-1
• IEC 60950-1
• C-Tick CISPR 22 Class B
• IC CISPR 22 Class B
• UL 60950-1
• VCCI CISPR 22 Class B
•RoHS
•WEEE
Sleep Button
Microphone
USB Port
