MXD/T-1000 10.1" Modero® X Series Touch Panels
MXD-1000 Specifications
Power Requirements: PoE (Power over Ethernet), 802.3af, class 3
Power Consumption: • Full-On: 8W maximum
• Standby: 3.2 W
• Shutdown: 1 W
Front Panel Components:
NFC Transceiver: Antenna and transceiver for Near Field Communications device detection and
interaction.
Light Sensor: Photosensitive light detector for automatic adjustment of the panel brightness.
Motion Sensor: Proximity detector to wake the panel when it is approached.
• Typical Range: 1 foot (30.48 cm)
• Maximum Range: 3 feet (91.44 cm)
• Range width: 10 degrees
LED Indicator: Camera active indicator (landscape only)
Sleep Button: Single button on edge of panel for placing panel in sleep mode, for powering off
the panel, and for accessing the Settings Pages.
Microphone: -42dB ± 3dB sensitivity FET microphone
Speakers: 4 ohm, 2 Watt, 300Hz cutoff frequency
Camera (landscape only: HD 720P camera for video conferencing/video chat support.
Rear Panel Components:
USB Port: USB connector used for keyboard and mouse connections, or for firmware
uploads.
Micro-USB Port: 5-pin Micro-USB connector used for video output from camera video
(Landscape Only) and microphone output only.
Ethernet 10/100 Port: 10/100 Base-T RJ-45 connector for Ethernet connectivity and PoE.
Touch Panel Display:
Display Type: TFT Active Matrix Color LCD with In-Plane Switching (IPS) technology.
Display Size: • Landscape: 9.9" x 6.7" (252 mm x 170 mm), 12.0" (304 mm) diagonal
• Portrait: 6.7" x 9.9" (170 mm x 252 mm), 12.0" (304 mm) diagonal
Viewable Area
(W x H):
• Landscape: 8.5" x 5.3" (217mm x 136mm), 10.1" (257mm) diagonal
• Portrait: 5.3" x 8.5" (136 mm x 217 mm), 10.1" (257mm) diagonal
Viewing Angle: • Vertical: ± 89°
• Horizontal: ± 89°
Screen Resolution
(W x H):
• Landscape: 1280x800
• Portrait: 800x1280
Aspect Ratio
(W x H):
• Landscape: 16:9
• Portrait: 9:16
Brightness: 400 cd/m2
Contrast Ratio: 700:1
Color Depth: 264K colors
Backlight Type: LED
Touch Overlay: Projected Capacitive; Multi-touch support, 3 simultaneous max.
Communications:
Ethernet: 10/100 port, RJ-45 connector and cable. Supported IP and IP-based protocols:
UCP, TCP, ICMP, ICSP, IGMP, DHCP, Telnet, FTP, DNS, RFB (for VNC), HTTP
USB: 1 - USB host 2.0, Type A ports
Near Field Communications
(NFC):
Supports standards ISO/IEC 15693, ISO/IEC 14443A, ISO/IEC 14443B;
Unique Identifier (UID), Typical Range = .25", Maximum Range = .5"
