Modero X® Series Touch Panels
8
MXD/T-1000 10.1" Modero® X Series Touch Panels
MXD-1000 Specifications (Cont.)
Communications (Cont.):
Bluetooth: HID Profile v1.1, Keyboard/Mouse Support, requires MXA-BT Bluetooth
Adaptor.
Video:
Streaming/File Formats: MPEG-TS for MPEG2; HTTP for MJPEG
Video Conferencing
(Landscape Only):
External application using on-board camera and microphone through
Micro-USB connection.
Audio:
Streaming/File Formats: WAV, MP3
Intercom: Full Duplex VoIP, SIP v2.0 (supported with AMX-CSG)
Operating
Environment:
• Operating Temperature: 32° F to 104° F (0° C to 40° C)
• Storage Temperature: 4° F to 140° F (-20° C to 60° C)
• Humidity Operating: 20% to 85% RH
• Humidity Storage: 5% to 85% RH
• Power ("Heat") Dissipation: On: 27.3 BTU/hr, Standby: 10.9 BTU/hr
Dimensions (HWD):
• Landscape: 6 11/16" x 9 7/8" x 2 5/8" (171 mm x 252 mm x 67 mm)
• Portrait: 9 7/8" x 6 11/16" x 2 5/8" (252 mm x 171 mm x 67 mm)
Weight:
2.0 lbs (0.91 Kg)
Certifications: • FCC Part 15 Class B
• C-Tick CISPR 22 Class B
• CE EN 55022 Class B and EN 55024
• CB Scheme IEC 60950-1
•IC
• IEC/EN-60950
•RoHS
Included Accessories: • MXD-1000 Installation Guide (93-5968-07)
• MXA-CLK Modero X Series Cleaning Kit (FG5968-16)
• MXD-1000 Installation Template (68-5968-03)
Other AMX Equipment: • PS-POE-AT, High Power PoE Injector (FG423-81)
• PS-POE-AF-TC, POE Injector, 802.3af Compliant (FG423-83)
• MXA-BT Bluetooth USB Adaptor (FG5968-19)
• CB-MXP10 Rough-In Box and Cover Plate for the 10" Wall Mount Modero X
Series Touch Panels (FG039-17)
• NXA-ENET8POE, Gigabit PoE Ethernet Switch (FG2178-62)
• NXA-ENET8-2POE, Gigabit Switch, 8 Port POE, 2 Port SFP (FG2178-63)
