AMX MXT-2001-PAN Installation & Hardware Reference Manual

Modero X Series G5 Touch Panels
7
Modero X® Series G5 Touch Panels - Installation & Hardware Reference Manual
Modero X Series G5 Touch Panels
Overview
The most elegant interface designed specifically for dedicated room control has been significantly enhanced to include a new G5
Graphic Engine to provide even faster and smoother animations and transitions, and we quadrupled the processing power with a
new Quad Core Processor. This new generation of touch panels is built for usability offering edge-to-edge capacitive touch glass
with multi-touch capabilities. It features advanced technology empowering users to operate AV equipment seamlessly, while
providing the ultimate in audio and video quality. The distinctive appearance will complement even the most sophisticated meeting
facilities and homes. With a lightning fast processor, brilliant graphics and enhanced capabilities, the Modero X Series is the control
surface that simply delivers more.
The Modero X Series G5 Touch Panels covered in this manual include:
NOTE: Note: The X Series G5 panels described in this document represent a different product family than the X Series (G4) touch
panels. For information on X Series G4 touch panels, refer to the Modero X Series G4 Touch Panels Instruction Manual.
FIG. 1
Modero X Series G5 Touch Panels
Modero X Series G5 Touch Panels
Name FG# Description Page Ref
MXT-2001-PAN FG5968-35 20.3" Modero X Series G5 Panoramic Tabletop page 11
MXD-2001-PAN-P
MXD-2001-PAN-L
Portrait: FG5968-36
Landscape: FG5968-37
20.3" Modero X Series G5 Panoramic Wall-Mounts page 13
MXT-1901-PAN FG5968-41 19.4" Modero X Series G5 Panoramic Tabletop page 16
MXD-1901-PAN-P
MXD-1901-PAN-L
Portrait: FG5968-42
Landscape: FG5968-43
19.4" Modero X Series G5 Panoramic Wall-Mounts page 18
MXT-1001 FG5968-47 10.1" Modero X Series G5 Tabletop page 21
MXD-1001-P
MXD-1001-L
Portrait: FG5968-48
Landscape: FG5968-49
10.1" Modero X Series G5 Wall-Mounts page 23
MXT-701 FG5968-53 7" Modero X Series G5 Tabletop page 26
MXD-701-P
MXD-701-L
Portrait: FG5968-54
Landscape: FG5968-55
7" Modero X Series G5 Wall-Mounts page 28
