AD9854
Rev. E | Page 45 of 52
Table 12. AD9854 Customer Evaluation Board (AD9854 PCB > U1 = AD9854ASVZ)
Item Qty
Reference
Designator
Device Package Value
Min
Tol
Manufacturer Manufacturer Part No.
1 3 C1, C2, C45 Capacitor 0805 805
0.01 μF,
50 V, X7R
10% Kemet Corp. C0805C103K5RACTU
2 21
C7, C8, C9, C10,
C11, C12, C13,
C14, C16, C17,
C18, C19, C20,
C22, C23, C24,
C26, C27, C28,
C29, C44
Capacitor 0603 603
0.1 μF,
50 V, X7R
10%
Murata
Manufacturing
Co., Ltd.
GRM188R71H104KA93D
3 2 C4, C37 Capacitor 1206 1206
27 pF,
50 V, NPO
5% Yageo Corporation CC1206JRNPO9BN270
4 2 C5, C38 Capacitor 1206 1206
47 pF,
50 V, NPO
5% Yageo Corporation CC1206JRNPO9BN470
5 3 C6, C21, C25 Capacitor TAJC TAJC
10 μF,
16 V, TAJ
10% AVX TAJC106K016R
6 2 C30, C39 Capacitor 1206 1206
39 pF,
50 V, NPO
5% Yageo Corporation CC1206JRNPO9BN390
7 2 C31, C40 Capacitor 1206 1206
22 pF,
50 V, NPO
5% Yageo Corporation CC1206JRNPO9BN220
8 2 C32, C41 Capacitor 1206 1206
2.2 pF,
50 V, NPO
0.25
pF
Yageo Corporation CC1206CRNPO9BN2R2
9 2 C33, C42 Capacitor 1206 1206
12 pF,
50 V, NPO
5% Yageo Corporation 1206CG120J9B200
10 2 C34, C43 Capacitor 1206 1206
8.2 pF,
50 V, NPO
0.5
pF
Yageo Corporation CC1206DRNPO9BN8R2
11 9
J1, J2, J3, J4, J5,
J6, J7, J25, J26
SMB STR-PC MNT N/A N/A Emerson/Johnson 131-3701-261
12 1 J10 40-pin header Header 40 N/A N/A Samtec, Inc. TSW-120-23-L-D
13 4 L1, L2, L3, L5 Inductor coil 1008CS 68 nH 2% Coilcraft, Inc. 1008CS-680XGLB
14 2 L4, L6 Inductor coil 1008CS 82 nH 2% Coilcraft, Inc. 1008CS-820XGLB
15 2 R1, R5 RES_SM 1206
49.9 Ω,
¼ W
1% Panasonic-ECG ERJ-8ENF49R9V
16 2 R2, R20 RES_SM 1206
3.92 kΩ,
¼ W
1% Panasonic-ECG ERJ-8ENF3921V
17 2 R3, R7 RES_SM 1206
24.9 Ω,
¼ W
1% Panasonic-ECG ERJ-8ENF24R9
18 1 R4 RES_SM 1206
1.3 kΩ,
¼ W
1% Panasonic-ECG ERJ-8ENF1301V
19 4
R6, R11,
R12, R13
RES_SM 1206
49.9 Ω,
¼ W
1% Panasonic-ECG ERJ-8ENF49R9V
20 1 R8 RES_SM 1206
2 kΩ,
¼ W
1% Panasonic-ECG ERJ-8ENF2001V
21 2 R9, R10 RES_SM 1206
100 Ω,
¼ W
1% Panasonic-ECG ERJ-8ENF1000V
22 4
R15, R16,
R17, R18
RES_SM 1206
10 kΩ,
¼ W
1% Panasonic-ECG ERJ-8ENF1002V
23 1 RP1
Resistor
network
SIP-10P 10 kΩ 2% Bourns 4610X-101-103LF
24 1 TB1 TB4
4-position
terminal
N/A N/A Wieland Electric, Inc.
Plug: 25.602.2453.0;
terminal strip: Z5.530.3425.0
25 1 U1 AD9854 SV-80 N/A N/A Analog Devices, Inc. AD9854ASVZ
26 1 U2 74HC125D 14 SOIC N/A N/A
Texas Instruments
Incorporated
SN74HC125DR
