AD9854
Rev. E | Page 46 of 52
Item Qty
Reference
Designator Device Package Value Manufacturer Manufacturer Part No.
Min
Tol
27 1 U3 Primary 8 SOIC N/A N/A ON Semiconductor Primary: MC10EP16DGOS
Secondary 8 SOIC N/A N/A ON Semiconductor
Secondary:
MC100LVEL16DGOS
28 4 U4, U5, U6, U7 74HC14 14 SOIC N/A N/A
Texas Instruments
Incorporated
SN74HC14DR
29 3 U8, U9, U10 74HC574 20 SOIC N/A N/A
Texas Instruments
Incorporated
SN74HC574DWR
30 1 J11 C36CRPX 36CRP N/A N/A
Tyco Electronics
Corporation
5552742-1
31 6
W1, W2, W3, W4,
W8, W17
3-pin header SIP-3P N/A N/A Samtec, Inc. TSW-103-07-S-S
32 10
W6, W7, W9,
W10, W11, W12,
W13, W14, W15,
W16
2-pin header SIP-2P N/A N/A Samtec, Inc. TSW-102-07-S-S
33 6
W1, W2, W3, W4,
W8, W17
Jumpers N/A Black N/A Samtec, Inc. SNT-100-BK-G
34 10
W6, W7, W9,
W10, W11, W12,
W13, W14, W15,
W16
Jumpers N/A Black N/A Samtec, Inc. SNT-100-BK-G
35 2 N/A
Self-tapping
screw
4–40, Phillips
pan head
N/A N/A 90410A107
36 4 N/A Adhesive feet N/A Black N/A 3M SJ-5518
37 1 AD9852/54 PCB N/A N/A N/A N/A GS02669 REV. E
38 2 R14, R19 RES_SM 1206
0 Ω,
¼ W
5% Panasonic-ECG ERJ-8GEY0R00V
39 4 N/A
Pin socket
(open end)
Tyco Electronics
Corporation
5-5330808-6
40 1 Y1 XTAL COSC N/A N/A Optional Optional
