To make a patch, you want to take an output to an input.
For example, to send an oscillator to the filter, put a pin at the cross point between
the VCO1 A(udio) column and the VCF A(udio) row.
Usually, patch audio outputs to audio inputs, and CV outputs to CV inputs. In some
cases, you can use audio signals (VCO audio outs) to modulate CV signals (usually
filter cut-off).
The X axis are outputs. Starting with audio signals on the left and CV signals on the
right of the matrix.
The Y axis are inputs. Starting with audio signals at the top and CV signals at the
bottom.
Three patch pin colours are provided - each has different resistance.
Higher resistance will attenuate the signal.
Black Zero Ohms
Red 10K Ohms
Blue 100K Ohms
