HOW SIGNALS FLOW IN THE MATRIX
Some examples follow of basic patching using the matrix panel. These aren’t
complete sounds, since you would need to use multiple pins, and of course, also set
the knobs and switches where you need them to be. But it does give you a heads up on
how to get signals flowing.
The colour of pin shown in the examples is not critical. Details on pin usage are
elsewhere in the manual, but as a reminder, the colour indicates resistance. The higher
the resistance, the more attenuation of the signal.
Black equals zero ohms resistance.
Red equals 10K ohms resistance.
Blue equals 100K ohms resistance.
