BST100 MANUAL
5
5-2-3.
Press <ENTER> to Cranking Test interface. Start the engine as guide displayed in the screen.
5-2-4.
Test result will be displayed as below. Press <ESC> to return to the main menu.
Cranking Test Result Instruction
Reference Table (For 12V System)
Cranking Voltage
Discharge Ability
Action to Battery
> 10.5 V
Good
No Action
10.0 ～ 10.5 V
Normal
Recharging It
9.6 ～ 10.0 V
Bad
Replace It Soon
< 9.6 V
Very Bad
Replace It Immediately
5-3. Charging Test
5-3-1.
Turn on the engine and set all electric systems, such as headlights, A/C system and multi-media
system, to maximum load status.
