Andamiro AVENGERS - Exploded Views and Part Identification; Side Payout Guide Part Details; Moving Pusher Component Details

10) SIDE PAYOUT GUIDE L, R PART
11)
MOVING PUSHER PART
626ZZ
1
MZZZ0BEA087
5
PUSHER BEARING
696ZZ
1
MSBP0PRO002
NO
PART NAME
SPEC
Q'TY
CODE NO
1
SIDE PAYOUT GUIDE MOLD
-
2
MDCC0PLA010
3
PHOTO-INT1(ANGLE) PCB ASS'Y
ANGLE TYPE
1
AZZZ0PCB103
4
MOTOR
KGV-2-0350-KB3640S1
1
MZZZ0MOT152
1
MOVING PUSHER ROTATE GUIDE
ACRYL-5T
1
MAV20ACR010
2
BEARING
NO
PART NAME
SPEC
Q'TY
CODE NO
1
1
1
2
3
4
- 35 -
