18) SLOT WHEEL PART
19) TARGET WHEEL DECO COVER PART
6
TARGET WHEEL DECO COVER-C
PET 1T
1
AAV10ACP014
4
LED CAP
Φ15 LED CAP
1
MWOL0PLA002
5
TARGET WHEEL DECO COVER-B
PET 1T
1
AAV10ACP013
2
TARGET WHEEL DECO COVER-A
ACRYL 3T
1
AAV10ACP016
3
LED CAP
Φ20 LED CAP
1
MZZZ0PLA037
NO
PART NAME
SPEC
Q'TY
CODE NO
1
TARGET WHEEL LED PCB ASS'Y
-
1
AAV20PCB004
3
NEW BONUS SPIN LED PCB ASS'Y
-
1
AAV20PCB003
4
PHOTO INT01 PCB ASS'Y
-
1
ACIR0PCB011
1
STEPPING MOTOR
4S56Q-08576S
1
MZZZ0MOT167
2
SLOT WHEEL MOLD
-
1
MAV20PLA002
NO
PART NAME
SPEC
Q'TY
CODE NO
4
3
2
1
1
5
6
2
4
3
4
