The method of assembling 3pieces
a
b
a.
The lower foothold :
Release M12 bolts (10EA),
separate the body.
To put together, do that in
reverse order.
b.
The upper mechanism:
Release M12 bolts (10EA), take
the head apart. (check the solenoid,
micro switch, sensor wiring, and the
connector) To put together, do thaat
in reverse order.
The
method
of
controling
the
tension
or
spring
The
method
of
exchange
the
punchball
Loosen the bolt and fix the spring
by adjusting the bottom side of it
You should release M10 bolt.
The
method
of
exchange
the
micro
switch
The method of fixing the FRP cover
Replace it after releasing
M3 bolts (2EA)
Assemble the front part first, fix
the cover with a tool
[12]
