Andamiro PUMP IT UP SX - Mechanical Drawing; Component Part Numbers

2524
6
Connect the connector cables between the floor controller and main ass’y .
8 - M 6 X L 2 0
R E D ( 1 P )
B L U E
1
Mechanical Drawing
NO
1
2
3
4
5
6
NAME
BILLBOARD ACRYL
BILLBOARD ACRYL
BILLBOARD FIXING BRACKET
FORNT CRT ACRYL
FORNT CRT ACRYL
HANDLE ASS’Y R/L
WING ACRYL R/L
FLEXIBLE TUBE ASS’Y
CODE-NO
MPUS0ACR023
MPUG0ACR002
MO2001-046A
MPUS1ACR008
MPUG0ACR006
AM99-PUS06A/07A
C04001-023A/024A
AM99-PUSS11A
SX
GX
SX
GX
QTY
1
1
1
1
1
1
1
1
NOTE
