SERVICE INSTRUCTION
46ST ver. 4.1 – 46ST FS ver. 4.1.F
Tools required for service:
Allen key (4 mm.).
Allen key (5 mm.).
Screwdriver (small).
Winch handle.
ANDERSEN winch grease
1. Remove screws (1).
2. Remove self-tailing arm (2) and drum (4).
3. Remove screws (14).
4. Remove upper base (8), and place it in a safe and comfortable place before dismantling it !
5. Remove drive shaft (5). by using a finger or a winch handle.
6. To release the roller bearing (6), gently insert a small screwdriver between roller bearing
and base plate (8). Remove roller bearing.
7. Remove shafts (12.7, 13.7).
8. Remove and dismantle the two gear units.
9. Clean all parts in benzine. Remember to clean the gear teeth, roller bearing track and
bushing inside the drum (4).
10. Assemble in reverse order. During assemble, by the use of a small soft brush lightly grease
all gear teeth, drive shaft, roller bearing, shafts, pawls, springs and bushings. Pawls should
only be lubricated with a very thin film of ANDERSEN WINCH GREASE. It is very important
that pawls can move freely.
IMPORTANT: When assembling the winch, check the functioning of each pawl by pushing the
pawl against the spring. The pawls should move smoothly and automatically return to their normal
position, where the pawls engage with the teeth. If the pawls do not function correctly, clean and
lubricate the pawls and gears. Check the function of the pawls again to make sure that it works
correctly. If the pawls do not work correctly replace the springs and recheck the function.
Malfunctioning pawls may lead to unexpected failure of a loaded winch resulting in material
damage or fatal personal injury.
Service Kit No. 19 (art. no. 710019) contains spare parts for this winch.
For current World Wide Distributor list please see:
www.andersenwinches.com
