INSTALLATIONSECTION 3
FLUE
SYSTEMS
14
Optional Components for 150mm (concentric) (6in) Diameter Flue Size
Quantity Flue Length Part Description Part Number
1 1 mtr Flue Pipe with clamp E202
1 1 mtr Cutable Flue Pipe with clamp E203
1 0.5 mtr Flue Pipe with clamp E204
190º Elbow E205
145º Elbow E206
1 1360mm (54in) Vertical Flue Terminal E239
1 Flat roof flashing for vertical
flue terminal with adjustable cap E207
1 Roof flashing for pitched roofs
150mm (6in) dia vent size E208
1 Wall Clamp 150mm (6in) dia. E209
Flue Component Table for 200mm (concentric) (8in) Diameter Flue Size
(88 kWh/300,00 Btu/h and 105.6kW/360,000 Btu/h Input Models.
SUPPLIED KIT COMPONENTS
Quantity Flue Length Part Description Part Number
190º Elbow E215
1 600mm (24in) Horizontal Flue Terminal E240
1 Large Stepped Adopter
Connection Clamp E237
Optional Components for 200mm (concentric) (8in) Diameter Flue Size
Quantity Flue Length Part Description Part Number
1 1 mtr Flue Pipe with clamp E212
1 1 mtr Cutable Flue Pipe with clamp E213
1 0.5 mtr Flue Pipe with clamp E214
190º Elbow E215
145º Elbow E216
1 Flat roof flashing for vertical
flue terminal with adjustable cap E217
1 Roof flashing for pitched roofs
150mm (6in) dia flue size E218
1 Wall Clamp 200mm (8in) dia. E219
