Electrical safety
• Technical data for the appliance is specied on the type plate on the back.
• The plug must be plugged into a correctly installed earthed mains socket.
• Never modify the plug in any way. If the plug does not t the mains socket, contact an authorised electrician to
install an earthed mains socket.
• The mains socket should be easily accessible.
• Do not use an extension cord unless absolutely necessary. If using an extension cord, it must be approved for
the appliance.
• Always unplug the power cord before cleaning, service and/or any other work on the appliance.
TECHNICAL DATA
Rated voltage 230 V
~
50 Hz
Output 270 W
Air ow 100 m³/h
Dehumidifying capacity 10 l /24 h
Temperature range 5–35°C
Refrigerant R134A
Tank volume 2 l
Noise level 43 dB
Dimensions 300 x 410 x 212 mm
Weight 10.7 kg
DESCRIPTION
Control panel
1. Indicator lamp for full water container. Goes on when the water container is full, or not properly inserted.
2. Indicator lamp for automatic defrosting:
– Goes on when automatic defrosting is in progress.
– Flashes with 0.5 Hz if leakage of refrigerant is detected.
– Flashes with 2 Hz if there is a fault on the room temperature sensor.
– Flashes with 5 Hz if there is a fault on the evaporator temperature sensor.
– NOTE: If the indicator lamp for automatic defrosting starts ashing, unplug and then plug in the power cord again.
Contact your dealer if the fault persists.
3. Indicator lamp for continuous operation.
4. Indicator lamp for operating mode 40% relative humidity.
5. Indicator lamp for operating mode 50% relative humidity.
6. Indicator lamp for operating mode 60% relative humidity.
7. Mode selector. Press to select operating mode: Continuous dehumidication → 40% humidity → 50% humidity → 60% humidity →
continuous dehumidication.
8. Power switch. Press to start/switch o the dehumidier.
