16
LCD DISPLAY
During operation you can have the parameters described under point 3 (DISPLAY)
displayed. In addition, the selected charge program and the current process (CHARGE or
DISCHARGE) will also be displayed. An example of the LCD display can be seen in Fig. [3].
4 different display modes and 4 different charge programs have been selected here.
"Full" is displayed when the charge process is complete and the rechargeable battery is
supplied with maintenance charging.
After the "TEST" and "REFRESH" programs have ended, the display alternates between
"Full" and the measured discharge capacity in mAh/Ah.
The backlighting of the LCD display switches on when the mains is connected and
extinguishes after 30 seconds if no rechargeable batteries have been inserted. It is
illuminated so long as a charge process is running and extinguishes automatically 30
seconds after the last rechargeable battery has been fully charged. The lighting can be
activated for 30 seconds by pressing a function button. If a faulty rechargeable battery
is detected during the charge process, the backlighting remains on permanently.
FAULT RECTIFICATION
Display Possible cause Solution
"- --"
No rechargeable batteries have
been inserted/detected.
The rechargeable battery has been
incorrectly inserted (wrong polarity).
Insert the rechargeable
battery with correct polarity.
"0 00mA" or
"0 00mAh"
with "CHARGE
TEST"
The charger is taking a charging/
discharging break to protect the
rechargeable battery
Wait until the break is over,
the charge/discharge
process will be continued
automatically.
"Err" / "Lo"
alternating
The rechargeable battery has an
internal short-circuit (0V) and is
thus defective.
Remove the rechargeable
battery and dispose of it in
an environmentally friendly
manner.
