APPENDIX
2012-MAY-18 REV. 02 PAGE 37
CHECKFIRE MP-N Electric
Detection and Actuation System Manual
COMPONENT INDEX
Part Shipping Weight
No.
Assembly lb. (kg)
Main Assemblies
427312 CHECKFIRE MP-N Electric Detection and Actuation System Includes: 10 (4.5)
427300 Control Module (module contains nuts and washers for mounting to bracket)
416792 Manual Actuator
423525 Combined Mounting Bracket
416129 Cable with Connector
423423 Nitrogen Cartridge, LT-10-R (2)
53051 1/4 in. Check Valve (2)
79064 Label Package
53081 Ownerʼs Manual
416735 Gas Motor Actuator Shipping Assembly
427308 Battery Shipping Assembly (3.6 VDC) 1/4 (0.11)
426461 End of Line Resistor Assembly (Package of 10) 1/4 (0.11)
426520 End of Line Resistor Assembly (Single) 1/4 (0.11)
Accessory Equipment
71230 Linear Detection Wire, 356 °F (180 °C), 100 ft. (30.5 m) 2 (0.90)
71231 Linear Detection Wire, 356 °F (180 °C), 500 ft. (152.4 m) 10 (4.54)
416218 Spot Detector – 270 °F (132 °C) 1/4 (0.11)
416219 Spot Detector – 325 °F (163 °C) 1/4 (0.11)
416220 Spot Detector – 360 °F (182 °C) 1/4 (0.11)
416213 Spot Detector Connector Package (one required for each detector) 1/4 (0.11)
416214 Spot Detector Cable Clamp Package (for use with protective tubing) 1/4 (0.11)
–one required for each detector
416762 Spot Detector Cable Clamp Package (for use without protective tubing) 1/4 (0.11)
–one required for each detector
416215 Flex Protective Tubing – 100 ft. (30.5 m) 4 (1.81)
416221 Spot Detector Bracket 1 (0.45)
416784 Amp Crimp Tool – Spot Detector 1 (0.45)
416113 Pneumatic/Linear Detector 808-DRV 1 (0.45)
416216 Connector/Cable Assembly For Pneumatic/Linear Detector 1/4 (0.11)
416378 Cable Clips (Package of 50) For Pneumatic/Linear Detector 1/4 (0.11)
56691 Nylon Cable Ties (Pkg. of 20) 1 (0.45)
56692 Rubber Sleeves (Pkg. of 20) 1/4 (0.11)
428375 Splicing Device (For Linear Detection Wire) 1 (0.45)
423541 Release Circuit Test Module (9 VDC Battery Not Included) 1 (0.45)
428966 Cover Removal Tool 1/4 (0.11)
428042 Battery Extender Cable Assembly 1/4 (0.11)
426601 Extender Cable Assembly 1/4 (0.11)
416129 Gas Motor Cable Assembly 1/4 (0.11)
423524 RS232 PC Interface Cable Kit 1/4 (0.11)
57593 High Temperature Silicone Grease – dialectic/not a sealant (Dow Corning #4) 1/4 (0.11)
Recharge Materials
423423 Nitrogen Cartridge, LT-10-R (DOT/TC) 2 (0.90)
416756 Gas Motor Replacement 1 (0.45)
Spare Parts
427300 Control Module 2 (0.90)
57452 Manual Actuator 4 (1.80)
423525 Mounting Bracket – MP Module/Manual Actuator 2 (0.90)
416901 Detection/Output Module Assembly 1/2 (0.22)
427308 Battery Module Assembly 1/2 (0.22)
53051 Check Valve, 1/4 in. (Pkg. of 2) 1/2 (0.22)
427310 Installation and Maintenance Manual 1/4 (0.11)
416355 Operating Instruction Label Package 1/4 (0.11)
416735 Gas Motor Actuator 2 (0.90)
197 Visual Inspection Seal – –
423503 Hardware Kit
428964 4 Pack of Tamper-Proof Cover Screws 1/4 (0.11)
428970 Battery Straps and Screws (6 of Each) 1/4 (0.11)
428972 6 Pack of Cover Seals 1/4 (0.11)
428968 Front Cover Assembly 1/4 (0.11)
