Ansul Checkfire MP-N User Manual

COMPONENT DIMENSIONS (Continued)
Mounting Bracket – Part No. 423525
Spot Detector Connector Package – Part No. 416213
Spot Detector Bracket – Part No. 416221
Spot Detector Cable Clamp – Part No. 416762
Spot Detector – Part No. 416114, 416115 and 416116
Gas Motor Actuator – Part No. 416735
APPENDIX
2012-MAY-18 REV. 02 PAGE 39
CHECKFIRE MP-N Electric
Detection and Actuation System Manual
4.25 IN.
(108 mm)
2.75 IN.
(70 mm)
1.25 IN.
(32 mm)
2.98 IN.
(75 mm)
8.7 IN.
(221 mm)
8.31 IN.
(211 mm)
3.78 IN.
(96 mm)
9.5 IN.
(241 mm)
002756
2.63 IN.
(67 mm)
6 IN.
(152 mm)
6.7 IN.
(170 mm)
1 IN.
(25 mm)
000856
003913
.28 DIA.
(7 mm)
5.25 IN.
(133 mm)
