ASC+ System Auto Split Charge & Engine Start Protect
User Guide and Installation Instructions
Document No 13362 Issue 04 Page 21 of 21
24V System spares
Antares Part No Description Type / Value
80245 Contactor 24V, 125A Latching
80299 Contactor 24V, 250A Latching
81337 Switch Kit 24V, 2 x Switches ASC + ESP
56180 LED 24V Green
82524 Contactor Loom 4 way, 5M, Connector to free end
82516 Switch Assembly Loom 6 way, 5M, Connector to free end
See note 1 below Controller 24V, 2 x contactor
Note 1: Identifying the controller
The controller (a black box approximately 100mm x 70mm) has a label on the front,
this label contains two numbers that identify the controller’s hardware (HW) and
software (SW) and therefore function and options fitted e.g.:-
HW: 81744-01 – SW: 17164-02
Both of these numbers must be quoted when requesting a replacement.
Note 2: Mixed contactors
On all systems the contactor ratings (not voltage) can be mixed. i.e. 125A contactor for
ASC & 250A contactor for ABP.
End of manual.
