Antares ASC+ - ASC settings

ASC+ System Auto Split Charge & Engine Start Protect
User Guide and Installation Instructions
Document No 13362 Issue 04 Page 20 of 21
Battery low disconnect voltage Single ABP: 10.5
or 21 volts.
Dual ABP: 10.5 &
12.2 volts, or 21 &
24.4 volts.
May be set in the range 10 to
12.25 volts or 20 to 24.5 volts
ASC settings:
Parameter
Default Alternative settings
Dual voltage sense Enabled Main sense only
or
Aux sense only
Ignition off forces ASC off Disabled Enabled
Battery sensing (battery present
or absent)
Enabled Disabled
Assured start activation External switch Crank signal input
or
Automatic detection
Switching hysteresis Standard May be set in the range 0.1 to
2.0 volts
Spares
12V System spares
Antares Part No Description Type / Value
80244 Contactor 12V, 125A Latching
80298 Contactor 12V, 250A Latching
81333 Switch Kit 12V, 2 x Switches ASC + ESP
56178 LED 12V Green
82524 Contactor Loom 4 way, 5M, Connector to free end
82516 Switch Assembly Loom 6 way, 5M, Connector to free end
See note 1 below Controller 12V, 2 x contactor
